This compact Alta labs AP6W wall mounted access point has been designed with hospitality in mid, making it the perfect access point for hotel, restaurants, resorts, entertainment venues and Multi Dwelling units.
FEATURES
• Versatile Design
• Bluetooth Setup
• Scalable Cloud-Based Management
• Mobile App
• AltaPass™ Multi-Password Technology
• Advanced Filtering - DPI Engine
• Hotspot Functionality
• On-The-Fly Changes and Scanning
• Wireless Network Color Coding
• SSID Broadcasting Flexibility
• Customizable Dashboard
• Status Snapshots
| Manufacturer |
Alta Labs |
| Manufacturer SKU |
AP6W |
| Use Environment |
Indoor |
| Wifi Standards |
802.11a/b/g/n/ac/ax (WiFi4/WiFi5/WiFi6) |
| Wireless Security |
WPA2-PSK, WPA2-SAE, WPA-Enterprise (WPA2/WPA3) |
| Frequency Bands |
Dual Band 2.4GHz and 5GHz |
| Data Rate |
2.4 GHz: Up to 574 Mbps, 5 GHz: Up to 2.4 Gbps |
| Concurrent Users |
250+ |
| Antenna Gain |
2.4 GHz: Up to 4.0 dBi, 5 GHz: Up to 4.1 dBi |
| Operating Temperature |
0 to 40° C (32 to 104° F) |
| Humidity |
5 to 90% Noncondensing |
| Power Supply |
PoE+ Enabled Network Switch, 48V, 0.5A PoE Adapter, or a 12VDC
1.5A Power Supply (Optional - Not Included) |
| POE Pass Through |
Yes |
| Max Power Consumption |
14.2W |
| Supported Voltage Range |
42.5-57V DC |
| POE |
802.3af/at |
| Networking interface |
Ethernet, WiFi, Bluetooth |
| Management interface |
(3) GbE RJ45 Ports |
| Dimensions |
156.1 x 90 x 43.9 mm
|
| Weight |
0.312 kg |
| Mounting
|
Wall |
| Manufacturers Datasheet |
Datasheet |
| Manufacturer Warranty |
2 Years |
