| Model |
SP 600 |
SP 800 |
SP 1000 |
SP 1500 |
SP 2000 |
| General Features |
| Nominal power (VA) |
600 |
800 |
1000 |
1500 |
2000 |
| Active power (W) |
360 |
480 |
600 |
900 |
1200 |
| Technology |
Line interactive VI |
Line interactive VI |
Line interactive VI |
Line interactive VI |
Line interactive VI |
| Waveform |
Simulated sinewave |
Simulated sinewave |
Simulated sinewave |
Simulated sinewave |
Simulated sinewave |
| Input |
| Nominal voltage (V) |
230 |
230 |
|
|
|
| Voltage range (V) |
170-290 |
170-290 |
170-290 |
170-290 |
170-290 |
| Frequency (Hz) |
50 - 60 ± 5Hz |
50 - 60 ± 5Hz |
50 - 60 ± 5Hz |
50 - 60 ± 5Hz |
50 - 60 ± 5Hz |
| Output |
| Voltage (V) |
230 ± 10% |
230 ± 10% |
230 ± 10% |
230 ± 10% |
230 ± 10% |
| Frequency (Hz) |
50 - 60 ± 1Hz |
50 - 60 ± 1Hz |
50 - 60 ± 1Hz |
50 - 60 ± 1Hz |
50 - 60 ± 1Hz |
| Protections |
| Full protection
|
Overload, short circuit, discharge, overcharge and surge protection |
Overload, short circuit, discharge, overcharge and surge protection |
Overload, short circuit, discharge, overcharge and surge protection |
Overload, short circuit, discharge, overcharge and surge protection |
Overload, short circuit, discharge, overcharge and surge protection |
| Type |
Fuse |
Fuse |
Fuse |
Fuse |
Fuse |
| Surgerating |
312J |
312J |
312J |
312J |
312J |
| Batteries |
| Number of batteries
|
1 |
1 |
2 |
2 |
2 |
| Battery series Type / Voltage |
VRLA 7 Ah
|
VRLA 9 Ah |
VRLA 7 Ah
|
VRLA 9 Ah |
VRLA 9 Ah |
| Communication and Management |
| Interface |
RGB LED bar (green / orange / red) |
RGB LED bar (green / orange / red) |
RGB LED bar (green / orange / red) |
RGB LED bar (green / orange / red) |
RGB LED bar (green / orange / red) |
| USB HID
|
Type B |
Type B |
Type B, RS232 |
Type B, RS232 |
Type B, RS232 |
| Alarms |
Visual (LED bar), Audible (buzzer) |
Visual (LED bar), Audible (buzzer) |
Visual (LED bar), Audible (buzzer) |
Visual (LED bar), Audible (buzzer) |
Visual (LED bar), Audible (buzzer) |
| NAS Compatibility
|
YES |
YES |
YES |
YES |
YES |
| Mechanical Features |
| Measurements W x D x H |
120 x 330 x 138mm |
120 x 330 x 138mm |
120 x 330 x 138mm |
148 x 380 x 173mm |
148 x 380 x 173mm |
| Net Weight (kg) |
4.8 |
5.5 |
8.6 |
9.6 |
10.3 |
| Environmental Conditions |
| Operating temperature |
0-40 °C |
0-40 °C |
0-40 °C |
0-40 °C |
0-40 °C |
| Relative humidity (%) |
< 95 (without condensing) |
< 95 (without condensing) |
< 95 (without condensing) |
< 95 (without condensing) |
< 95 (without condensing) |
| Noise level (dB)
|
≤ 40 |
≤ 40 |
≤ 40 |
≤ 40 |
≤ 40 |
| Certifications |
| Standards and marks
|
EN 62040-1, EN 62040-2, CE |
EN 62040-1, EN 62040-2, CE |
EN 62040-1, EN 62040-2, CE |
EN 62040-1, EN 62040-2, CE |
EN 62040-1, EN 62040-2, CE |
